Throttle Pedal And Brake Hydraulic System - Valid For Rhd


Schematic: Throttle Pedal And Brake Hydraulic System - Valid For Rhd
Loc
Part
Cond       Price
1
BRAKE PEDAL
134276 (1) Full qty
1
BRAKE PEDAL
149290 (1) Full qty
2
PEDAL RUBBER
132819 (1) Full qty
2
PEDAL SLAB
149292 (1) Full qty
3
Brake lever
129609 (1) Full qty
4
Ball joint
109407 (1) Full qty
5
Clutch spring short Daytona
101305 (1) Full qty
6
Spring anchor pin
129612 (1) Full qty
7
Washer
112125 (1) Full qty
8
Shim 0,9 mm.
112127 (1) Full qty
8
Shim 1,1 mm.
112129 (1) Full qty
8
Shim 1,2 mm.
112130 (1) Full qty
8
Shim 1,0 mm.
112128 (1) Full qty
8
Shim 1,3 mm.
112131 (1) Full qty
9
Stud for air pump
13543421 (4) Full qty
10
HOSE
136315 (1) Full qty
11
Screw
16043124 (2) Full qty
12
Fork
10007871 (1) Full qty
13
New       Price on Enquiry
16102311 (1) Full qty
BS00703n
14
Screw
130926 (1) Full qty
15
Nut
16104411 (1) Full qty
16
Brake Light Switch
133555 (1) Full qty
16
New       Price on Enquiry
133555 (1) Full qty
ET02508n
17
Nut
- (1) Full qty
18
Nut
16104111 (4) Full qty
19
Do Not Use - See GE07667n
12601374 (4) Full qty
19
New       £ 0.12
12601374 (4) Full qty
CH11905n
20
RUBBER HOSE
132411 (1) Full qty
21
Clamp
12179190 (2) Full qty
23
BRACKET
140498 (1) Full qty
24
Wavy Lock Washer 8mm
127496 (2) Full qty
25
Small bracket with sheathing
10441590 (1) Full qty
26
Nut
12575411 (1) Full qty
27
BRAKE PIPE
143676 (1) Full qty
28
Screw
129636 (1) Full qty
29
Nut
12574211 (1) Full qty
30
Stud bolt
13517121 (1) Full qty
31
Washer
130861 (1) Full qty
32
UNION
136311 (1) Full qty
33
Union
131873 (2) Full qty
34
Gasket
131874 (4) Full qty
35
PIPE FROM CLUTCH PUMP TO TANK
151845 (1) Full qty
37
Tubo sfiato dal bocchettone
105959 (1) Full qty
38
GASKET
144824 (1) Full qty
