Front Cover Ancillaries


Schematic: Front Cover Ancillaries
Schematic: Front Cover Ancillaries
Loc
Part
Cond       Price
1
Front Cover Oil Pump Shaft Bush 250/275
New       £ 24.92
24712 (1) Full qty
TC11341n
2
Stud 8X45 P2
New       Price on Enquiry
95920416 (2) Full qty
GE35633n
3
Axle Case Centre Ring Dowel (8.2x11mm)
New       £ 4.79
92791 (2) Full qty
AX22415n
4
Oil Pump Housing Late 250/275
New       £ 405.35
24710 (1) Full qty
SU00049n
5
Oil Pump Pivot Post 250/275
New       £ 27.45
24112 (1) Full qty
SU11673n
5
Pivot 250GTE 275GTB4
Used       £ 25.25
24112 (1) Full qty
SU11673u
6
Oil Pump Post Roll Pin
New       £ 5.15
SU11194n (1) Full qty
SU11194n
7
Stud (M6x24) Angle Drive/Water Pump
New       £ 3.58
CH11551n (6) Full qty
CH11551n
8
Oil Pump Top Hat Bush 250/275
New       £ 27.12
34334 (1) Full qty
SU12101n
9
Oil Pump Body Bush
New       £ 27.23
24673 (1) Full qty
SU11210n
10
Bell Housing Stud (M8x33mm)
New       £ 4.79
CC11467n (5) Full qty
CC11467n
11
Distributor Drive/Oil Pump Drive Gear Woodruff Key [13x5x3mm]
New       £ 4.60
CC11216n (1) Full qty
CC11216n
12
Oil Pump Gear Set 250,275 (Fuel Pump Drive)
New       £ 961.95
24711 (1) Full qty
SU11306n
12
Oil Pump Driving Gear 250/275
New       £ 264.39
24711 (1) Full qty
SU11903n
13
Oil Pump Buddy Gear 250/275
New       £ 203.89
24110 (1) Full qty
SU11905n
14
Oil Pump Lower Bush 250/275
New       £ 39.60
24111 (1) Full qty
SU12080n
15
Front Cover Gasket Late 250
New       £ 27.23
22572 (1) Full qty
TC00048n
16
Front Cover 250 SWB 168 Comp C/W Chain Covers
New       £ 9498.50
TC00120n (1) Full qty
TC00120n
17
Bearing
New       Price on Enquiry
95890204 (2) Full qty
CS11532n
17
Front Cover/Water Pump Bearing
New       £ 48.35
95890204 (2) Full qty
TC00018n
18
Water Pump Sprocket
New       £ 325.49
22135 (1) Full qty
CC11152n
18
Water Pump Sprocket 250/275
New       £ 332.63
22135 (1) Full qty
CS11152n
19
Front Cover Oil Pump Cover Top Hat Bush 250/275
New       £ 29.65
34335 (1) Full qty
SU11232n
20
Oil Pump Front Plate Gasket 250/275
New       £ 19.57
22570 (1) Full qty
SU00024n
20
Oil Pump Gasket
New       Price on Enquiry
22570 (1) Full qty
SU11712n
21
Water Pump Shaft 250/275
New       £ 329.41
26493 (1) Full qty
CS11314n
22
Oil Pump Front Cover Plate 250 Early
New       £ 344.85
22562 (1) Full qty
SU00076n
22
Oil Pump Front Cover Plate 250 Early
Used       Price on Enquiry
22562 (1) Full qty
SU00076u
23
Water Pump Bearing Circlip 37mm Internal
New       £ 0.54
TC14185n (1) Full qty
TC14185n
24
Water Pump Oil Seal 250,275,330 19x32x7
New       £ 5.27
1932/7 (1) Full qty
CS11356n
25
Water Pump Large Gasket
New       £ 8.42
26496 (2) Full qty
CS00022n
26
Water Pump Large Inner Body
New       £ 387.20
26491 (1) Full qty
CS00062n
26
Water Pump Large Inner Body ( Used )
Used       £ 387.20
26491 (1) Full qty
CS00062u
27
Water Pump Spacer Sleeve Upgraded 19OD (To Suit CS11757n)
New       £ 51.43
26495 (1) Full qty
CS11252n
27
Water Pump Spacer Sleeve
Used       Price on Enquiry
26495 (1) Full qty
CS11252u
27
Water Pump Spacer Sleeve Upgraded 20OD (To Suit ST00278n)
New       £ 53.35
26495 (1) Full qty
CS11253n
27
Water Pump Spacer 250/275
New       £ 22.39
26495 (1) Full qty
CS11296n
28
Water Pump Face Seal 38mm
New       £ 82.59
95850601 (1) Full qty
CS11293n
28
Water Pump Seal
New       Price on Enquiry
95850601 (1) Full qty
CS12005n
29
Water Pump Impeller Back Plate/Thrust Face
New       £ 63.89
26644 (1) Full qty
CS11270n
30
Water Pump Impeller Large 250/275
New       £ 221.03
26492 (1) Full qty
CS11290n
31
Water Pump Impeller Lock Tab
New       Price on Enquiry
100434 (1) Full qty
CS11584n
31
Water Pump Lock Tab
New       £ 5.54
100434 (1) Full qty
CS11807n
32
Water Pump Domed Nut
New       £ 12.05
100436 (1) Full qty
CS11344n
32
Water Pump Acorn Nut
New       Price on Enquiry
100436 (1) Full qty
CS11582n
33
Water Pump To Water Transfer Pipe Gasket 250,275
New       £ 6.95
26498 (1) Full qty
CS00014n
34
Water Pump To Front Water Pipe Gasket 250,275
New       £ 3.25
26331 (1) Full qty
CS00012n
34
Block To Water Transfer Pipe Gasket 250/275
New       £ 3.39
26331 (1) Full qty
CS00025n
34
Front Water Pump Pipe Gasket 250 GTE/SWB
New       £ 8.25
26331 (1) Full qty
CS11777n
35
Water Transfer Pipe
New       £ 252.29
26499 (1) Full qty
CS00056n
35
Water Transfer Pipe
Used       Price on Enquiry
26499 (1) Full qty
CS00056u
36
Nut M6 250
New       Price on Enquiry
GB00304n (2) Full qty
GB00304n
37
M6 Wavy Washer 250
New       Price on Enquiry
GB00233n (2) Full qty
GB00233n
38
M6 Plain Washer
New       Price on Enquiry
GE00045n (2) Full qty
GE00045n
39
Water Pump Large Outer Housing
New       £ 545.44
26490 (1) Full qty
CS00064n
40
Chain Tensioner Lock Nut
New       Price on Enquiry
TC11250n (1) Full qty
TC11250n
41
Chain Tensioner Screw Washer M16
New       £ 0.29
TC14189n (1) Full qty
TC14189n
42
Chain Tensioner/PRV Fibre Washer
New       £ 1.64
SM00131n (3) Full qty
SM00131n
43
Chain Tensioner Screw
New       £ 27.23
22489 (1) Full qty
TC11238n
44
M10 Spring washer 250
New       Price on Enquiry
GE35508n (1) Full qty
GE35508n
45
Nut M10x1.0
New       Price on Enquiry
94666 (1) Full qty
GE00043n
46
Timing Chain Tensioner Housing
New       £ 396.88
22488 (1) Full qty
TC11326n
47
Chain Tensioner/Oil Filler Tube O Ring
New       £ 0.91
TC11327n (1) Full qty
TC11327n
48
Chain Tensioner Gasket
New       £ 5.15
220290 (1) Full qty
TC00064n
49
Chain Tensioner Sprocket Needle Rollers
New       £ 0.72
92618 (19) Full qty
TC11202n
50
Chain Tensioner Sprocket
New       £ 390.53
22153 (1) Full qty
TC11154n
51
Chain Tensioner Pin
New       £ 220.83
22144 (1) Full qty
TC11308n
52
3.2 x 40 Split Pin
New       £ 0.24
10734801 (1) Full qty
FS41063n
53
Chain Tensioner Pin Washer
New       £ 8.42
22145 (1) Full qty
TC13423n
54
Chain Tensioner Fork
New       £ 603.79
22142 (1) Full qty
TC11318n
54
Chain Tensioner Fork
22142 (1) Full qty
54
Chain Tensioner Fork
22142 (1) Full qty
54
Timing Chain Tensioner Fork Base 250 TR
New       £ 62.65
22142 (1) Full qty
TC14215n
54
Chain Tensioner Fork Wth Long Pin
New       £ 846.95
22142 (1) Full qty
TC14217n
55
Chain Tensioner Spring
New       £ 20.52
22258/104565 (1) Full qty
TC11322n
56
M10 Plain Washer
New       Price on Enquiry
GB00306n (1) Full qty
GB00306n
57
Chain Tension Clamp Bolt
TC11240n (1) Full qty
58
Auxiliary Drive Pulley Nut
New       £ 0.79
TC11196n (1) Full qty
TC11196n
59
M12 Spring Washer Black
New       £ 1.05
10517070 (1) Full qty
GE35635n
60
M12 Plain Washer
New       £ 2.04
GE35545n (1) Full qty
GE35545n
61
Auxiliary Drive Pulley
New       £ 477.95
22688 (1) Full qty
TC11140n
61
Auxiliary Drive Pulley
Used       Price on Enquiry
22688 (1) Full qty
TC11140u
62
Oil Seal 26/47/7
New       Price on Enquiry
95850108 (1) Full qty
GE00502n
62
Aux Drive Housing Seal 26x47x10
New       £ 7.13
95850108 (1) Full qty
TC13391n
63
Auxiliary Housing Circlip 42mm Internal
New       £ 0.54
TC14187n (1) Full qty
TC14187n
64
Auxillary Drive Bearing
New       £ 15.43
101298 (2) Full qty
TC00020n
64
Bearing
New       Price on Enquiry
101298 (2) Full qty
TC14164n
65
Drive Gear Aux Woodruff Key Larger Radius [13x5x4mm]
New       £ 4.60
CC11214n (1) Full qty
CC11214n
66
Auxiliary Drive Shaft
New       £ 357.83
22567 (1) Full qty
TC11138n
67
Auxiliary Drive Housing
New       £ 397.49
22566 (1) Full qty
TC00068n
68
Auxiliary Drive Front Cover Gasket 250/275
New       £ 3.58
22554 (1) Full qty
TC00019n
68
Gen. Drive Gasket
22554 (1) Full qty
69
Auxiliary Drive Shaft Circlip 25mm External
New       £ 0.54
TC14183n (1) Full qty
TC14183n
70
Auxiliary Drive Sprocket
New       £ 321.84
22549 (1) Full qty
TC11150n
70
Auxiliary Drive Sprocket
Used       Price on Enquiry
22549 (1) Full qty
TC11150u
71
Oil Filter (Full Flow)
New       £ 36.12
100325 (1) Full qty
SU10012n
72
Oil Filter Union
New       £ 39.33
100327 (1) Full qty
SU11529n
72
Oil Filter Union
Used       Price on Enquiry
100327 (1) Full qty
SU11529u
73
PRV O Ring
New       £ 1.52
SU11519n (1) Full qty
SU11519n
74
Late PRV Body Circlip
New       £ 0.08
SU11919n (1) Full qty
SU11919n
75
Late PRV Body Aluminium Washer
New       £ 0.21
SU11985n (1) Full qty
SU11985n
76
Late PRV Body
New       £ 393.25
SU11266n (1) Full qty
SU11266n
77
PRV Piston Late
New       £ 70.79
SU11236n (1) Full qty
SU11236n
78
PRV Spring Late 250,275
New       £ 26.02
SU11244n (1) Full qty
SU11244n
79
Late PRV Adjuster Screw
New       £ 120.40
SU11410n (1) Full qty
SU11410n
80
PRV Lock Nut Late
New       £ 58.69
SU11277n (1) Full qty
SU11277n
81
PRV Assembly Brass Top Hat Cover Late
New       £ 181.45
SU11234n (1) Full qty
SU11234n
82
Cam Cover Front Plate 2-Bolt
New       £ 136.49
CH00072n (1) Full qty
CH00072n
83
Cam Sprocket Cover O Ring
New       £ 0.91
28530 (1) Full qty
CH11987n
83
O-Ring
New       Price on Enquiry
28530 (1) Full qty
GE00236n
84
Rivet (Screw Type for Tags) Steel 6.28x3.97x2.53
New       £ 1.10
GE35502n (4) Full qty
GE35502n
85
Fuel Pump Spacer Block
34382 (1) Full qty
86
Fuel Pump Gasket 250,275,330
34365 (2) Full qty
87
Mechanical Fuel Pump Drive Gearbox Housing
New       £ 1996.50
FU13511n (1) Full qty
FU13511n
88
Bearing F/C Mounted Fuel Pump 10x26x8
New       £ 27.23
FU13519n (3) Full qty
FU13519n
89
Fuel Pump Drive Gear
FU11184n (1) Full qty
90
Mechfuel Pump Drive G/Box Plate to Front Cover Gasket
New       £ 10.42
FU14327n (1) Full qty
FU14327n
91
Mechanical Fuel Pump Gearbox Housing Dowel
New       £ 5.39
FU15788n (2) Full qty
FU15788n
92
Fuel Pump Cover Drive Gasket 2…
SU00012n (1) Full qty
93
Bearing F/C Mounted Fuel Pump 15x32x8
New       £ 31.16
FU13521n (1) Full qty
FU13521n
94
Fuel Pump Driven Gear
FU00134n (1) Full qty
95
Fuel Pump Plunger (Short)
FU11254n (1) Full qty
96
Front Cover Firing Order Tag
New       £ 75.63
22573 (1) Full qty
TC11324n
97
Late PRV Housing Brass Bung M16x1.5
New       £ 3.25
SU11989n (1) Full qty
SU11989n
98
Late PRV Housing
New       £ 1754.50
37.047.570 (1) Full qty
SU11408n
99
PRV Gasket 250/275
New       £ 1.76
24713 (1) Full qty
FU00113n
100
Crank Bolt Cover Late 250
New       £ 165.17
CC00069n (1) Full qty
CC00069n
101
Front Cover Crank Bolt Cover Gasket
New       £ 6.66
TC00012n (1) Full qty
TC00012n
102
Oil Pressure Take Off (Large Hole)
New       £ 63.89
SU11689n (1) Full qty
SU11689n
103
Oil Pressure Take Off/Blanking Plug Reg. Washer
New       £ 0.15
10151 (1) Full qty
SU11987n

Need Help With Your Order?

Call Our Sales Team On: +44 (0) 118 940 1101

[PART_NAME] has been added to your basket

Indicator/Brake Cluster 250 Cal Spider

[PART_NAME]

  • GTO PN: [PART_NUM]
  • Ferrari PN: [FER_NUM]
  • Price: £[PART_CUR_PRICE]
  • Quantity: [QTY]
View Quote
